Thông số kỹ thuật
| Model/Series | HDL-PTZ902LR-Z90 | |
| Camera parameters | Image Sensor | 1/1.8″ Progressive CMOS |
| Effective Pixels | 1920[H]*1080[V] | |
| Signal to noise ratio | 55dB | |
| Image Enhancement | BLC, HLC, 3D DNR, Defog, EIS, Distortion Correction | |
| Day and night | automatic / manual | |
| Lens focal length | 6mm-540mm, 90x optical zoom | |
| Drive mode | Video [DC drive] | |
| Lens aperture | F1.8 | |
| Detection Distance | 20~2000m | |
| Coding compression | main processor | Hi3516 |
| Compression standard | H.265/H.264 High Profile /MJPEG | |
| Stream parameters | 32K～20Mbps | |
| Audio compression | G.711 | |
| Audio bit rate | 64Kbps | |
| Network Interface | Mobile phone monitoring | Support Windows Mobile,Symbian,iPhone Platform Smartphone monitor |
| Network protocol | PPPoE,DHCP,TCP/IP,HTTP,RTP/RTCP,RTSP,UPN P,SMTP,FTP,ONVIF | |
| WIFI/satellite | Optional support for 802.11b / g protocol, 2.4GHz or military satellite channel | |
| 4G/5G module | Optional internal or external EVDO/WCDMA/TD-SCDMA modules | |
| Network Interface | 10M/100M adaptive Ethernet port | |
| Alarm interface | Support/optional | |
| Management mode | IE / standalone management software/NVR/decoder/CMS platform server/third-party management platform | |
| Networking information | Wired/wireless [WIFI/spread spectrum microwave/4G/satellite, etc.] support SDI/CVI/IP or analog multi-mixed mode networking | |
| Laser specifications | Laser power | 15W |
| Laser wavelength | 808nm/940nm | |
| Laser angle | Synchronize motion adjustment with camera zoom | |
| PTZ specifications | Load mode | Vertical device |
| Horizontal speed | 0.01~100°/s | |
| Vertical speed | 0.01~30°/s | |
| Rotation angle | 0~360° | |
| Cruise/scan | 6 articles | |
| Automatic homing | support | |
| Preset position | 256 | |
| Vertical angle | +40°~-75° | |
| Cover material | Aluminum alloy, stainless steel lock, window: transparent glass; top open-top design, easy to install the equipment | |
| Shield size | 18 inch, 23 inch, 29 inch single window shield [depending on the type of matching] | |
| Temperature control | Built-in automatic thermostat,-35℃～65℃ | |
| Other | Protection class | IP66 |
| Input voltage | AC24V/DC24 | |
| Power consumption | ≤60W | |
| Peripheral power supply | Optional solar and wind power supply system | |
| net weight | 15KG | |
